LH12300

Name: LH12300
Brand: AMPS
SKU: LH12300

£838.80

Tax included. Shipping calculated at checkout.

SKU: LH12300

Quantity

Technical Specifications Description Downloads

UID	LH12300
Battery Chemistry	LiFePO4 (Lithium Iron Phosphate)
Battery nominal voltage	12 V
Amphour capacity	300
Watt/hour capacity	3840
Charge limit	["300"]
Discharge limit	["300"]
Bluetooth	Yes
BMS	Integrated / Included
Terminals	M8
Mass	{"value":28.4,"unit":"kg"}
App	AMPS BMS
Operating Voltage	12.8 V (4S x 3.2 V)
Warranty	["5 Years"]
Heating	100w
DIMS	470 x 190 x 240 mm

No product family information available.

Part No	Nominal Voltage	Charge Current	Discharge current	Nominal Capacity	Actual Capacity
LH12300	12V	300A	300A	300Ah	300Ah

Battery Capacity	300 Ampere hour (200Ah) \| 3840Wh LH12300

Nominal Voltage	12V
Heating Element	yes, 100W

Battery Chemistry	LiFePO4 Chemistry - Prismatic cells

Series Limit	4 (48V bank)

Parallel Limit	Infinite

Dimensions and Weight	47L x 19W x 24H (cm) - 27.4kg

Operating Temperature	Charge - 0'C to 60'C // Discharge from -20'C to 60'C - Integrated heater for low temperature operation

Operating Voltage	13.6V (4S x 3.4V)

Charge Voltage	14.2V-14.6V, 14.4V recommended

Float Voltage	13.4V-14.0V, 13.8V recommended

Max Continuous Charge Rate	1C (300A)

Max Continuous Discharge Rate	1C (300A)

BMS Features	Bluetooth interface for battery information
	Low temperature battery disconnect (0'C for charge, -20'C for discharge)
	Over voltage disconnect (14.8V or above on input)
	Low voltage disconnect
	Cell imbalance disconnect (Cell voltage differential of above 0.3V)
	Automatic cell voltage balancing
	Over current disconnect protection
	Short circuit protection


Operational Quiescent Current	10mA

Standby Quiescent Current	0.1mA



Charge Curve	Constant Current / Constant Voltage - CC/CV

Terminals	M8

Warranty	5 years
